The Preferred Diesel Specialists Solution

Diesel System Test Bench

The Comprehensive Solution for Every Advanced Diesel Service Center

DOWNLOAD COMPLETE CATALOG

DOWNLOAD MTBR|X-W CATALOG

catalog/MTBR|X/MTBRX_Products_Focus_Points_Hor_05.png

MTBR|X-W

[1] Pump Testing

• 5-15 minutes testing time per pump

• CRp / GDp Pump (All Brands and Types).

• Capable for all EU6 technologies with Sync Operation such as Denso HP5,

Bosch CP4-EU6, VDO EU6 technology and more...

• Heavy-Duty CR pump (CPN5S2, CAT, Cummins etc.)

[4] Injectors Testing & Coding*

• 6-12 minutes testing and coding* time for 4 injectors

• CRi / CRiN / GDi injectors (All Brands and Types).

• Capable for all EU6 technologies such as VCC and NCC technology, iART, PCRS5,

• XPI, F2E, F2P, F2R Injectors pumps and more...

• CRIN 4.2 Heavy Commercial-Vehicle injectors

• Large Diesel Engine CRiN injector (QSK, MTU, L ’Orange, etc...)

[1] HEUi Testing & Coding*

• 6-8 minutes testing and coding* time per injector

• Dynamic and static measurement of the actual overflow

• Dual-Coil HEUi Injector testing capable

[1] EUi/EUp Testing & Coding* (requires HK1400A Cambox)

• 6-10 minutes testing and coding* time per injector

• Capable for all EU6 technologies

• Expandable to Future Systems

CGL - Authorized Continental / VDO “Blind-Lift”

Measurement of Piezo-Stack

Code(SKU) CZ-008783

MTBR|X-W

Based on 0 reviews. - Write a review

Qty

Add to Wish List Compare this Product

Capable to efficiently Diagnose and fully Calibrate all Makes and Types of CRDi’s, EUI’s, EUP’s, HEUI’s, CR-pumps, GDi-pumps and GDi injectors.

A Continental/VDO Authorized Test Bench Xtremely Fast Testing Times without any Compromise New Design for every Service Station Optimized Working Area access [240o] & Component

Set-up Times 2800Bar Operating Pressure EU6 Systems Testing and Coding* Capabilities Coding capability for all brands and types available in the market today. Bosch, Denso, Delphi, Continental /VDO, CAT, Cummins*, John Deere, ISUZU*, HINO*, KOMATSU*, E1/ E3/ DAF/ Smart Pump, F2E/ F2P/ F2R* technologies and more added every day...

Off-Highways CR applications testing and coding (John Deere, Komatsu, Hino, Isuzu) Cummins XPI*, Caterpillar-Perkins C4/C6 and other Medium and Heavy-Duty testing and coding Advanced water-cooling or air-cooling system to optimize long term nonstop operation at all environmental conditions.
